Draughtsman Mechanical

NQR Code:QG-04-CG-03930-2025-V2-CGSSC

  • Old Code: QG-04-CG-03930-2025-V2-CGSSC

    Copy
About this Qualification

Job Description

A Draughtsman Mechanical is responsible for developing 3D drawings of design specifications for mechanical equipment and components. The individual selects and uses the appropriate Computer-Aided Design (CAD) software and equipment for the purpose, depending on the type and complexity of the drawing functions to be carried out. The person collaborates with engineers, production technicians and clients to identify design problems and develop effective solutions.

Eligibility Criteria

Criteria 1 Criteria 2 Experience Training Qualification
12th Passed No Experience Equivalent
2nd Year of 3 Year Diploma after 10th Completed No Experience Equivalent
10th Passed 2 years NTC/NAC/CITS
10th Passed 3 years Equivalent
Previous NSQF qualification of Level 3.5 1.5 Years None
Previous NSQF qualification of Level 3 3 years None

Progression Pathway

  • Designer Mechanical - 5
  • Computer aided tool and die design engineer -6

Learning Module In Job Role/Qualifcation

National Occupation Standards (NOS)/Module NOS Code Mandatory/ Optional Estimated size (Hours) Nos Credit Level
Follow the health and safety practices at work CSC/N1335 Mandatory 60 2 3
Coordinate with co-workers to achieve work efficiency CSC/N1336 Mandatory 30 1 3
Create and modify 3D mechanical engineering drawings using the CAD / CAM Software CSC/N0402 Mandatory 330 11 4
Employability Skills (30 hours) DGT/VSQ/N0101 Mandatory 30 1 2
