Printed Circuit Board Technician

This course provides an overview of Printed Circuit Board (PCB) technology, starting with an exploration of basic concepts such as electronic component packages, types of PCBs, and the history of PCB development. Participants gain insight into Electronic Design Automation (EDA) tools, with a focus on customizing Autodesk Eagle for in-depth analysis and design. The curriculum delves into component types, including through-hole packages, and emphasizes adherence to design rules. Participants learn the CAD workflow and the importance of manufacturing documentation. Additionally, they develop proficiency in creating PCB flowcharts, understanding layering and materials, and simulating electronic circuits to analyze waveform outputs. Furthermore, the course covers Film Master generation methods, material selection, and assembly techniques for both leaded and surface-mounted devices, along with familiarization with assembly tools. Through this comprehensive training, participants acquire fundamental knowledge crucial for PCB design and manufacturing processes.
