JUNIOR DESIGNER CAD/CAM

NQR Code:QG-4.5-CG-02404-2024-V1-MSME

  • Old Code: QG-4.5-CG-02404-2024-V1-MSME

    Copy
About this Qualification

Job Description

The qualification containing different modules which is required for the job role CAD/CAM Engineer, this qualification ultimately helps learner in the following: ● To be expertise in CAD/CAM/CAE Software Application ● To get an employment in Engineering/ Manufacturing industries ● To become an entrepreneur

Eligibility Criteria

Criteria 1 Criteria 2 Experience Training Qualification
3 year Diploma after 10th In relevant field No Experience None
3rd Year of 3 Year Diploma after 10th Pursuing No Experience None
Previous NSQF qualification of Level 4 1.5 Years None
Previous NSQF qualification of Level 2 2 years None

Progression Pathway

  • Designer – CAD/ CAM

Learning Module In Job Role/Qualifcation

National Occupation Standards (NOS)/Module NOS Code Mandatory/ Optional Estimated size (Hours) Nos Credit Level
Create & Modify Part Model using CAD Software MSME/MCCCC/01 & Version 1.0 Mandatory 90 3 4.5
Generate Part Program Using CAM Software (CAM) MSME/MCCCC/02 & Version 1.0 Mandatory 90 3 4.5
Analyze Part Model MSME/MCCCC/03 & Version 1.0 Mandatory 90 3 4.5
Design Surfaces using Higher end CAD Software MSME/MCCCC/04 & Version 1.0 Mandatory 120 4 4.5
Generate CNC Program MSME/MCCCC/05 & Version 1.0 Mandatory 90 3 4.5
Employability Skills MSME/ES /02 Mandatory 60 2 4.5
OJT NA Mandatory 60 2 4.5
