Jr. Technician -Tool & Die Maker

NQR Code:QG-3.5-CG-02402-2024-V1-MSME

  • Old Code: QG-3.5-CG-02402-2024-V1-MSME

    Copy
About this Qualification

Job Description

Learners who attain this qualification are competent in Tool and Die Manufacturing and can get a job in a captive or commercial Tool Room. Qualified Learners can set up their own Tool and Die manufacturing unit that leads to make an entrepreneur.

Eligibility Criteria

Criteria 1 Criteria 2 Experience Training Qualification
10th Passed No Experience None
Previous NSQF qualification of Level 3 1.5 Years None
Previous NSQF qualification of Level 2.5 3 years None

Progression Pathway

  • Technician- Tool and Die Maker

Learning Module In Job Role/Qualifcation

National Occupation Standards (NOS)/Module NOS Code Mandatory/ Optional Estimated size (Hours) Nos Credit Level
Create Part Drawing using CAD MSME/CCTDM/01 & Version 1.0 Mandatory 150 5 3.5
Checking dimensions of machined Part MSME/CCTDM/02 & Version 1.0 Mandatory 30 1 3.5
Manufacturing of Tool & Die Parts MSME/CCTDM/03 & Version 1.0 Mandatory 240 8 3.5
Use and Application of Engineering Materials MSME/CCTDM/04 & Version 1.0 Mandatory 30 1 3.5
Design of Press Tool MSME/CCTDM/05 & Version 1.0 Mandatory 150 5 3.5
Assist in Operation of CNC Machine MSME/CCTDM/06 & Version 1.0 Mandatory 150 5 3.5
Design of Mould MSME/CCTDM/07 & Version 1.0 Mandatory 150 5 3.5
Create & Modify part using higher End software MSME/CCTDM/08 & Version 1.0 Mandatory 90 3 3.5
Generate Part Program for CNC Machine using CAM MSME/CCTDM/09 & Version 1.0 Mandatory 90 3 3.5
Employability Skills MSME/ES/03 Mandatory 120 4 3.5
